| Part Number | Color | Mounting Plate | Diameter | Electrical Ratings | Packaging |
|---|---|---|---|---|---|
| PA8H | Natural | None | 0,75 – 1,5 mm² 22-12 AWG, Cu |
17.5 A, 450 V, -25°C to T110 20 A, 300 V, 105°C (221°F) |
50 Pcs/Bag 500 Pcs/Ctn |
| PA10H | Natural | None | 1 – 2,5 mm² 22-10 AWG, Sol Cu 14-10 AWG, Str Cu |
24 A, 450 V, -25°C to T110 30 A, 300 V, 105°C (221°F) |
50 Pcs/Bag 500 Pcs/Ctn |
| PA12H | Natural | None | 2,5 – 6 mm² 22-10 AWG, Cu |
41 A, 500 V, -25°C to T110 35 A, 300 V, 105°C (221°F) |
40 Pcs/Bag 400 Pcs/Ctn |
| PA14H | Natural | None | 4 – 10 mm² 20-8 AWG, Cu |
57 A, 500 V, -25°C to T110 50 A, 300 V, 105°C (221°F) |
25 Pcs/Bag 250 Pcs/Ctn |
| PA16H | Natural | None | 6 – 16 mm² 14-6 AWG, Cu |
76 A, 500 V, -25°C to T110 68 A, 300 V, 105°C (221°F) |
10 Pcs/Bag 200 Pcs/Ctn |
| PA18H | Natural | None | 10 – 25 mm² 12-4 AWG, Cu |
101 A, 500 V, -25°C to T110 87 A, 300 V, 105°C (221°F) |
10 Pcs/Bag 100 Pcs/Ctn |
