FOSP-K - High-temperature Optical Fiber Protection Sleeve

Applications

FOSP-K is composed of 304 stainless steel, PVDF hot-melt tube, and PVDF heat-shrinkable tube three different material components. It can be in an environment of 150˚C for long-term use. It is used in automotive optical radar and other optical fiber connection point protection in high-temperature environments. Providing good mechanical strength protection for fiber splicing.

Approvals / Specifications

Operating Temperature Range

  • Continuous operating temperature: -40℃ ~ 150℃

COLOR

Standard color: clear, (Special sizes are available on request.)
Characteristics
  •  Excellent moisture resistance and protection performance
  • Transparent sleeve makes the fusion easier before shrinkage
  • Can be used conveniently and avoid damage to the optical fiber during installation
  • Excellent flame retardance
  • Excellent electrical and chemical performance

  1. Fusion tube
  2. Steel rod
  3. Heat shrinkable tubing
