HB3 - Busbar Insulating Heat Shrink Tubing (Withstand Voltage Up To 36kV)

Applications

Heavy wall HB3 has reliable insulation protection. It can provide insulation and anti-flashover protection for busbars up to 36kV. The cross-linked polyolefin material has UV resistance and flame retardant properties, and can provide long-term insulation and withstand voltage protection for busbars in harsh high temperature and chemical environments.

Approvals / Specifications

IEC60060-1

Operating Temperature Range

  • Continuous operating temperature: -45℃ ~ 105℃
  • Minimum shrink temperature: 100℃
  • Full recovery temperature: Above 135˚C

COLOR

Standard color: red, (Busbar width will vary depending on the design of the manufacturer. The recommended size is for reference only.)
Characteristics
  • Shrink ratio: 2.5:1
  • Flexibility and corrosion resistance
  • Excellent chemical resistance and insulation performance
